Description
ENGINE
• Engine type: Liquid cooled, 4-stroke, SOHC, 4-valve
• Cylinder arrangement: Single Cylinder
• Displacement: 155 cm³
• Bore & stroke: 58.0 x 58.7mm
• Compression ratio: 11.6:1
• Maximum horse power: 11.3kW(15.4PS)/8000r/min
• Maximum torque: 13.9N・m(1.4kgf m)/6500r/min
• Starting system: Electric Starter
• Lubrication system: Wet sump
• Engine oil capacity: 1 Liter
• Fuel supply system: Fuel Injection
• Clutch type: Dry, centrifugal, shoe
• Transmission type: V-belt automatic
CHASIS
• Frame type: Backbone
• Front suspension: Telescopic fork
• Rear suspension: Unit Swing
• Front tire: 110/70-13M/C 48P Tubeless
• Rear tire: 130/70-13M/C 63P Tubeless
• Front brake: Hydraulic single disc brake
• Rear brake: Hydraulic single disc brake
DIMENSION
• Overall length x width x height: 1935mm x 740mm x 1160mm
• Seat height: 765mm
• Wheelbase: 1340mm
• Minimum ground clearance: 125mm
• Wet weight (with oil and a full fuel tank): 131kg for NMAX ABS
• Fuel tank capacity: 7.1L
ELECTRICAL
• Ignition system type: TCI(Transistor Controlled Ignition)
• Battery: YTZ6V
• Headlight: LED
• Tail light: LED
STANDARD EQUIPMENT
• Meter panel: Digital
• Stop & start system: Equipped
• Nmax abs &abs (anti-lock brake system): Equipped
• Y-connect: Equipped
• Traction control system: Equipped
• Smart key: Equipped
• Electric socket: Equipped
Note: Available in Visayas and Mindanao only
