Yamaha Motorcycle Mio Aerox S

Description

Yamaha Motorcycle Mio Aerox S
ENGINE
• Engine Type: Liquid cooled, 4-stroke, SOHC, 4-valve
• Cylinder Arrangement: Single Cylinder
• Displacement: 155 cm3
• Bore & Stroke: 58.0 x 58.7mm
• Compression Ratio: 11.6:1
• Maximum Horse Power: 11.3kW(15.4PS)/8000r/min
• Maximum Torque: 13.9N・m(1.4kgf・m)/6500r/min
• Starting System: Electric starter
• Lubrication System: Wet Sump
• Engine Oil Capacity: 1.0 L
• Fuel Supply System: Fuel Injection
• Clutch Type: Dry, Centrifugal Shoe
• Transmission Type: V-belt automatic

CHASSIS
• Frame Type: Backbone
• Front Suspension: Telescopic Fork
• Rear Suspension: Unit Swing
• Front Tire: 110/80-14M/C 53P Tubeless
• Rear Tire: 140/70-14M/C 62P Tubeless
• Front Brake: Mio Aerox S – Hydraulic single disc brake (230mm)
• Rear Brake: Mechanical leading trailing drum brake

ELECTRICAL
• Ignition System Type: TCI (Transistor Controlled Ignition)
• Battery: Mio Aerox S – YTZ7V
• Headlight: LED
• Tail Light: LED
• Dimensions Overall (L x W x H): 1980mm X 700mm X 1150mm
• Seat Height: 790mm
• Wheelbase: 1350mm
• Minimum Ground Clearance: 145mm
• Wet Weight (with oil and a full tank): Mio Aerox S – 124kg
• Fuel Tank Capacity: 5.5L
