Description
Engine
• MAX POWER: 6.9kW / 7,500 RPM
• MAX TORQUE: 9.5Nm / 6,500 RPM
• ENGINE TYPE: 4-Stroke, Single Cylinder, SOHC, 2-Valve
• BORE X STROKE: 53.5mm x 55.2mm
• ENGINE DISPLACEMENT: 124.1cc
• COMPRESSION RATIO: 9.6:1
• FUEL SYSTEM: Fuel Injection
• COOLING SYSTEM: Air-Cooled
• LUBRICATION: Wet Sump
• STARTING: Electric / Kick
• IGNITION SYSTEM: Fully Transistorized
• ENGINE OIL: 1L
• TRANSMISSION TYPE: CVT
• CLUTCH TYPE (PRIMARY): Automatic Centrifugal Dry Type
Chassis
• SUSPENSION (FRONT): Telescopic Coil Spring, Oil Damped
• SUSPENSION (REAR): Swingarm Type, Oil Damped
• TIRE SIZE (FRONT): 70 / 90-14M / C 34 P
• TIRE SIZE (REAR): 70 / 90-14M / C 40 P
• BRAKES (FRONT): Disc
• BRAKES (REAR): Drum
• FUEL TANK CAPACITY: 4L
Dimensions
• OVERALL LENGTH: 1885mm
• OVERALL WIDTH: 655mm
• OVERALL HEIGHT: 1040mm
• WHEELBASE: 1260mm
• GROUND / ROAD CLEARANCE: 140mm
• CURB MASS: 108kg
• SEAT HEIGHT: 760mm
• DRY WEIGHT: 106kg
Note: Available in Visayas and Mindanao only
* Price inclusive of Credit Card and Bank Charge
