Description
Basic Specification
• Cooling Capacity
– 3.50 (1.02-4.20) kW
– 12,600 (3,670-15,120) kJ/h
• EER (min-max): 14.00 (14.12-12.81) kJ/hW
– Electrical Data
– Voltage: 230 V
– Current: 4.1 A
– Power Input (min-max): 900 (260-1,180) W
• Moisture Removal
– 2.0 L/h
– 4.2 Pt/h
• Air Circulation
– Indoor: 12.5 m³/min (440 ft³/min)
– Outdoor: 30.9 m³/min (1,090 ft³/min)
• Noise Level
– Indoor (H / L / Q-Lo): 40/28/19 dB(A)
– Outdoor (H): 48 dB(A)
• Dimensions (Indoor)
– Height: 295 mm (11-5/8 inch)
– Width: 870 mm (34-9/32 inch)
– Depth: 229 mm (9-1/32 inch)
• Dimensions(Outdoor)
– Height: 542 mm (21-11/32 inch)
– Width: 780 mm (30-23/32 inch)
– Depth: 289 mm (11-13/32 inch)
• Net Weight
– Indoor: 10 kg (22 lb)
– Outdoor: 23 kg (51 lb)
• Refrigerant Pipe Diameter
– Liquid Side: ø 6.35 mm (1/4 inch)
– Gas Side: ø 9.52 mm (3/8 inch)
• Pipe Extension
– Chargeless Pipe Length: 7.5 m
– Maximum Pipe Length: 20 m
– Maximum Elevation Length: 15 m
– Additional Refrigerant Gas*: 10 g/m
– Power Supply: Outdoor
Comfort Features
• iAUTO-X: Yes
• Humidity Sensor: Yes
• ECO Mode with A.I.: Yes
• Inverter Control: Yes
• Sleep Mode: Yes
• Quiet Mode: Yes
• Soft Dry Operation Mode: Yes
• Personal Airflow Creation: Yes
Clean Air Features
• nanoe™ X: Yes
• nanoe-G: Yes
• Odour Removing Function: Yes
• Removable Washable Panel: Yes
Convenience Features
• 24-Hour Dual ON & OFF Real Setting Timer: Yes
• LCD Wireless Remote Control: Yes
• Wireless LAN Remote Control (For Internet Connection): Yes (Built-in)
• Wired Remote Control: Yes (Optional)
Realibility Features
• Random Auto Restart: Yes (32 Restart Patterns)
• Blue Fin Condenser: Yes
• Long Piping (max.): 20 m
• Top Panel Maintenance Access: Yes
• Self-Diagnostic Function: Yes
Note: Available in Visayas and Mindanao
