Samsung 2.5HP WindFree™ Wall-mount Air Conditioner Comfort Inverter AR60H24D1FWNTC

Description

Samsung Aircon AR60H24D1FWNTC
Capacity
• Capacity (Cooling, kJ/h): 23400 kJ/hW
• Capacity (Cooling, Min – Max, kJ/h): 5000 – 27000 kJ/hW
Noise Level
• Noise Level (Indoor, High/Low, dBA): 42 / 29 dBA
• Noise Level (Outdoor, High/Low, dBA): 52 dBA

Electrical Data
• Power Source(Φ/V/Hz): 1 / 220-240~/ 50/60Hz
• Power Consumption(Cooling, W): 2000 W
• Operating Current(Cooling, A): 8.8 A

Physical Specification
• Net Dimension (Indoor, WxHxD, mm): 1055*299*215 mm
• Net Dimension (Outdoor, WxHxD, mm): 790*548*285 mm
• Net Weight (Indoor, kg): 11.5 kg
• Net Weight (Outdoor, kg): 27.4 kg

Technical Information
• Piping Length (Max, m): 30 m
• Piping Height (Max, m): 15 m
• SVC Valve (Liquid (ODxL)): 6.35
• SVC Valve (Gas (ODxL)): 15.88
• Moisture Removal (l/hr): 2.30 l/hr
• Air Circulation (Cooling, ㎥/min): 18.60 ㎥/min
• Refrigerant (Type): R32
• Refrigerant (Charging, tCO2e): 0.46 tCO2e
• Low Ambient (Cooling, ℃): 16~46 ℃
• Outdoor Unit (Compressor Type): BLDC
• Outdoor Unit (Anti-Corrosion Fin): Yes

Air Flow
• WindFree Cooling: Yes
• Air Direction Control (Up/Down): Auto
• Air Direction Control (Left/Right): Auto
• Air Flow Control Step (Cool/Fan): 5/4

Air Purification
• PM 1.0 Filter: No
• Tri Care Filter: No
• 4-in-1 Care Filter: No
• Copper Anti-bacterial Filter: Yes
• Auto Clean (Self Cleaning): Yes

Convenience
• SmartThings: Yes
• AI Auto Cooling: Yes
• Motion Detect Sensor: No
• Freeze Wash: Yes
• Beep On/Off: Yes
• 24-Hour Timer: Yes
• Auto Restart: Yes

Operating Mode
• Auto Mode: Yes
• Fast Cool: Yes
• Dry Comfort: Yes
• Good Sleep: Yes
• Eco Mode: Yes
• Dehumidification: Yes
• Fan Mode: Yes
• Quiet: Yes

Smart
• WiFi Embedded: Yes

App Connectivity
• SmartThings App Support: Yes

Note: Available in Visayas, Mindanao and Palawan area.
