Kolin 1HP Split Type Inverter Aircon KS-IW10-MCAI12O1M32

Description

Kolin Aircon KS-IW10-MCAI12O1M32
Full Specification
• Nominal Capacity: 1.0 hp
• Cooling Capacity: 9,800 (2,940 – 10,780) kJ/h
• Power Supply: 230 V~ / 60 Hz / 1 Ph
• Power Input: 930 (186 -1,116) W
• Input Current: 4.5 (1.01 – 4.62) A
• Rated Power: 1,900 W
• Rated Current: 9.00 A
• CSPF Rating: 5.58
• Star Rating: ⭐⭐⭐⭐⭐
• Area (Unloaded Space): 17 m²

Indoor Unit
• Indoor air flow (Hi/Mi/Lo): 605 / 550 /400 m³/h
• Sound Pressure level: 34/31/18 dB(A)
• Unit Dimension (WxDxH): 723 x 199 x 286 mm
• Net Weight: 7.1kg
• Package Dimension (WxDxH) 780x270x360 mm
• Gross Weight: 9.3 kg

Outdoor Unit
• Refrigerant Type: R32
• Refrigerant Charge: 0.32 kg
• Outdoor Sound Pressure Level: 52 dB(A)
• Outdoor Airflow: 1300 m³/h
• Unit Dimension (WxDxH): 668 x 252 x 469 mm
• Unit Weight: 16.7 kg
• Packaging Dimension (WxDxH): 765 x 270 x 515 mm
• Gross Weight: 18.3 kg
• Installation Pipe Size (High Side): 1/4″
• Installation Pipe Size (Low Side): 3/8″
• Maximum Pipe Length: 25 m
• Maximum Height Distance: 10 m
• Circuit Breaker: 20 A

Note: Available in Visayas, Mindanao and Palawan area.
