Panasonic 1.5HP Split Type Deluxe Inverter CS/CU-XPU12WKQ

Description

Cooling Capacity (min-max)

• kW: 3.06 (1.02-3.80)

• Btu/h: 11,020 (3,670-13,680)

Electrical Data

• Voltage (V): 230

• Current (A): 3.4

• Power Input (min-max) (W): 750 (245-1,170)

EER (min-max)

• Btu/hW: 14.69 (14.98-11.69)

Moisture Removal

• L/h: 1.7

• Pt/h: 3.6

Air Circulation

• Indoor m³/min (ft³/min): 10.8 (380)

• Outdoor m³/min (ft³/min): 31.6 (1,120)

Noise Level

• Indoor (H / L / Q-Lo) dB(A): 38/28/21

• Outdoor (H) dB(A): 48

Dimensions Indoor (Outdoor)

• Height

– mm: 290 (542)

– inch: 11-7/16 (21-11/32)

• Width

– mm: 779 (780)

– inch: 30-11/16 (30-23/32)

• Depth

mm: 209 (289)

inch: 8-1/4 (11-13/32)

Net Weight

• Indoor kg (lb): 8 (18)

• Outdoor kg (lb): 23 (51)

Refrigerant Pipe Diameter

• Liquid Side

– mm: ø 6.35

– inch: 1/4

• Gas Side

– mm: ø 9.52

– inch: 3/8

Pipe Extension

• Chargeless Pipe Length (m): 7.5

• Maximum Pipe Length (m): 20

• Maximum Elevation Length (m): 15

• Additional Refrigerant Gas* (g/m): 10

Power Supply

• Outdoor

Note: Available in Visayas and Mindanao only
