Description
Engine
• Engine type: Air cooled, 4-stroke, SOHC, 2-valve
• Displacement: 125cm3
• Bore & Stroke: 52.4mm x 57.9mm
• Compression ratio: 10.0:1
• Maximum Horse Power: 6.0kW(8.2PS)/7000r/min
• Maximum torque: 10.2N??m(1.0kgf??m)/4500r/min
• Starting System: Electric starter & Kickstarter
• Lubrication: Wet Sump
• Cylinder layout: Single cylinder
• Clutch type: Wet, multiple-disc
• Carburetor Type/Fuel supply: Carburetor
• Headlight: Halogen bulb 12V,35/35W?1
• Primary / Secondary Reduction ratio: 3.409 (75/22) / 3.214 (45/14)
• Transmission type: Constant mesh, 4-speed
• Caster angle / Trail: 26 degree / 89mm
Dimension
• Overall Length ? Width ? Height: 2,040mm x 700mm x 1,070mm
• Weight(with oil and a full fuel tank): 114kg
• Wheelbase: 1,265mm
• Minimum ground clearance: 170mm
• Fuel tank capacity: 7.6L
• Engine oil capacity: 1.10L
• Seat height: 800m
Framework
• Frame type: Diamond
• Suspension type(Front): Telescopic fork
• Suspension type(Rear): Swing arm
• Brake type(Front/Rear): Mechanical leading trailing drum brake
• Tire size(Front): 3.00×17(4PR) 43P Tube type
• Tire size(Rear): 3.00×17(4PR) 46P Tube type
• Brake / tail light: 12V, 21 / 5W ? 1
• Turn signal light(Front/Rear): 12V,10W ? 2
Note: Available in Visayas and Mindanao only
* Price is inclusive of Credit Card and Bank Charge
